DETAILS TECHNIQUES:
|
Chipset |
|
VIA VT82C694T North Bridge
VIA VT82C686B South Bridge
|
|
Bus Type |
|
1 AGP+ 5 PCI+ 1 ISA+ 1 AMR
|
|
CPU |
|
Support Socket 370 processors
Support Intel Tualatin Processors
Support Intel Pentium III FC-PGA processors
at 500/550/600/600-133/650/667-133/700/733-133/750/800-133/850/866-133/933-133/1000/1100/1130/1200/1260 MHz.
Support Intel Celeron processors at 533/533A/566/600/633/667/700/733/766/800/850/900/950/1000/1100/1200/1300 MHz
|
|
System Memory |
|
Three 168-pin 3.3V PC133 DIMM sockets
Support up to 1.5GB SDRAM
Support 66/100/133MHz Synchronous DRAM and 66MHz EDO DRAM
|
|
Power Management |
|
ACPI V1.0 and APM compliant
Support S0,S!,S3,S5 ACPI power status
Suspend to RAM and Suspend to Disk Support
Auto Adiust FAN speed in the difference power status
|
|
USB |
|
2 USB ports + 2
USB 1.1 specification compliant
|
|
Bus Speed |
|
66/100/133MHz FSB
|
|
BIOS |
|
Licensed advanced AWARD BIOS
2Mbit Flash ROM
Support Plug and Play
Support ACPI and OS Directed Power Management
|
|
Storage system |
|
Two PCI Master IDE ports support up to 4 IDE devices
Support "Ultra DMA33/66/100"
One floppy port support up to two 3.5" or 5.25" floppy drives(360K/720K/1.2M/1.44M/2.88M)
Support LS-120 floppy disk drive and ZIP drive
|
|
I/O Feature |
|
All I/O ports can be enabled/disabled by BIOS setup
1 Speaker+1 Line in+1 Mic
1 PS/2 keyboard prot
1 PS/2 mouse port
2 high speed Serial Ports(16550 fast UART compatible)
1Enhanced parallel Port (SPP, EPP, ECP)
IrDA port supports up to 115.2KB/sec transfer rate
|
|
Graphics |
|
AGP 4X Support
Universal AGP Slot
|
|
System Health Monitoring |
|
CPU temperature, system temerature, CPU fan speed and chassis fan speed, 5 system voltages
|
|
Onboard Audio |
|
AC'97 2.1 Compliant
16-bit Stereo Codec
|
|
Advanced Feature |
|
Supports wakeup on Lan/Modem
Trend ChipAway Virus on Guard
|
|
QDI Innovative Technology |
|
BIOS-ProtectEasy, ManageEasy, BootEasy, StepEasy, LogoEasy, SpeedEasy, RecoveryEasy
|
|
Board Size |
|
305 x 210 mm (ATX)
|
|
|
La carte est en parfait état d'aspect et de fonctionnement. Elle sera livée nue. Les drivers et manuel si besoin, sont disponibles sur le site constructeur : http://www.qdigrp.com/qdisite/eng/products/Advance10t.htm
|
